Renogy Core Mini 12.8V 300Ah LifePo4 Battery

Renogy Core Mini- 12V 300Ah Lithium Iron Phosphate Battery

You won't find a lighter 12V 300Ah Lithium Battery anywhere. With its ultralightweight, compact design, and low-temperature cut-off, this battery is perfect for both travel and home use.

Features:

• Compact design, 31% smaller than other 12V 300Ah LFP batteries.
• Weighs just 25kg, 57% lighter than the 12V 200Ah lead-acid battery.
• Low-temperature protection charging: <-20°C, discharging: < 65°C.
• Grade-A prismatic LiFePO4 cells deliver 5000+ cycles at 80% depth of discharge (DOD).
• 3840Wh capacity, maximum 4P4S configuration, expandable to 61.44kWh.
• 5-year warranty. Certified by FCC, CE, ROHS, UKCA, and more.

Electrical Specifications

• Rated Capacity (0.5C, 25°C): 300Ah
• Nominal Voltage: 6000W
• Nominal output Voltage RMS: 12.8V
• Energy: 3840Wh
• Cycle Life (0.5C/1C, 25℃): 5000 Cycles (80% DOD)

Charging Parameters

• Voltage Range: 10V to 14.8V
• Maximum Continuous Charge Current: 150A
• Discharging Parameters
• Maximum Continuous Discharge Current: 200A
• Peak Discharge Current: 380A @ 10s

Temperature Parameters

• Operation Temperature Range: Charge: 32°F to 140°F (0°C to 60°C)
• Operation Temperature Range: Discharge: -4°F to 149°F (-20°C to 65°C)
• Storage Temperature Range: -4°F to 140°F (-20°C to 60°C)
• Operation Relative Humidity: 5% to 95%

Mechanical Specifications

• Dimension (L x W x H): 15.12 x 7.64 x 9.96 in / 384 x 194 x 253 mm
• Weight: 55.1 lbs / 25.0 kg
• Terminal Bolt Size: M8 × 1.25 × 12 mm & M8 × 1.25 × 16 mm
• Protection Rating: IP65
• Certifications
• MSDS, UN38.3, FCC, CE, PSE, RCM, RoHS and UKCA: YES

Warranty

• 5-year material warranty
